4.6. Stability exercises#
Exercise 4.1
Determine the stability function of the following Runge-Kutta method
\[\begin{split} \begin{array}{c|ccccc}
0 & 0 & & & & \\
\frac{1}{4} & \frac{1}{4} & & & & \\
\frac{1}{2} & \frac{1}{2} & 0 & & & \\
\frac{3}{4} & 0 & \frac{1}{2} & \frac{1}{4} & & \\
0 & 0 & \frac{1}{6} & -\frac{1}{3} & \frac{1}{6} & \\ \hline
& -1 & \frac{2}{3} & -\frac{1}{3} & \frac{2}{3} & 1
\end{array} \end{split}\]
Solution
\[\begin{split} \begin{align*}
A &= \begin{pmatrix}
0 & 0 & 0 & 0 & 0 \\
\frac{1}{4} & 0 & 0 & 0 & 0 \\
\frac{1}{2} & 0 & 0 & 0 & 0 \\
0 & \frac{1}{2} & \frac{1}{4} & 0 & 0 \\
0 & \frac{1}{6} & -\frac{1}{3} & \frac{1}{6} & 0
\end{pmatrix}, &
\mathbf{b} &= \begin{pmatrix} -1 \\ \frac{2}{3} \\ -\frac{1}{3} \\ \frac{2}{3} \\ 1 \end{pmatrix}.
\end{align*} \end{split}\]
Computing the ceofficients
\[\begin{split} \begin{align*}
\mathbf{b}^\mathsf{T}A^0\mathbf{e} &=
\begin{pmatrix} -1 & \frac{2}{3} & -\frac{1}{3} & \frac{2}{3} & 1 \end{pmatrix}
\begin{pmatrix}
1 & 0 & 0 & 0 & 0 \\
0 & 1 & 0 & 0 & 0 \\
0 & 0 & 1 & 0 & 0 \\
0 & 0 & 0 & 1 & 0 \\
0 & 0 & 0 & 0 & 1
\end{pmatrix}
\begin{pmatrix} 1 \\ 1 \\ 1 \\ 1 \\ 1 \end{pmatrix} = 1, \\
\mathbf{b}^\mathsf{T}A\mathbf{e} &=
\begin{pmatrix} -1 & \frac{2}{3} & -\frac{1}{3} & \frac{2}{3} & 1 \end{pmatrix}
\begin{pmatrix}
0 & 0 & 0 & 0 & 0 \\
\frac{1}{4} & 0 & 0 & 0 & 0 \\
\frac{1}{2} & 0 & 0 & 0 & 0 \\
0 & \frac{1}{2} & \frac{1}{4} & 0 & 0 \\
0 & \frac{1}{6} & -\frac{1}{3} & \frac{1}{6} & 0
\end{pmatrix}
\begin{pmatrix} 1 \\ 1 \\ 1 \\ 1 \\ 1 \end{pmatrix} = \frac{1}{2}, \\
\mathbf{b}^\mathsf{T}A^2\mathbf{e} &=
\begin{pmatrix} -1 & \frac{2}{3} & -\frac{1}{3} & \frac{2}{3} & 1 \end{pmatrix}
\begin{pmatrix}
0 & 0 & 0 & 0 & 0 \\
0 & 0 & 0 & 0 & 0 \\
0 & 0 & 0 & 0 & 0 \\
\frac{1}{4} & 0 & 0 & 0 & 0 \\
-\frac{1}{8} & \frac{1}{12} & \frac{1}{24} & 0 & 0
\end{pmatrix}
\begin{pmatrix} 1 \\ 1 \\ 1 \\ 1 \\ 1 \end{pmatrix} = \frac{1}{6}, \\
\mathbf{b}^\mathsf{T} A^3 \mathbf{e} &=
\begin{pmatrix} -1 & \frac{2}{3} & -\frac{1}{3} & \frac{2}{3} & 1 \end{pmatrix}
\begin{pmatrix}
0 & 0 & 0 & 0 & 0 \\
0 & 0 & 0 & 0 & 0 \\
0 & 0 & 0 & 0 & 0 \\
0 & 0 & 0 & 0 & 0 \\
\frac{1}{24} & 0 & 0 & 0 & 0
\end{pmatrix}
\begin{pmatrix} 1 \\ 1 \\ 1 \\ 1 \\ 1 \end{pmatrix} = \frac{1}{24}, \\
\end{align*} \end{split}\]
therefore the stability function is
\[ R(z) = 1 + z + \frac{1}{2}z + \frac{1}{6}z^3 + \frac{1}{24}z^4. \]
Exercise 4.2
Determine the stability function of the following Runge-Kutta method. Is this an A-stable method?
\[\begin{split} \begin{array}{c|cc}
\frac{1}{4} & \frac{7}{24} & -\frac{1}{24} \\
\frac{3}{4} & \frac{13}{24} & \frac{5}{24} \\ \hline
& \frac{1}{2} & \frac{1}{2}
\end{array} \end{split}\]
Solution
\[\begin{split} \begin{align*}
A &= \begin{pmatrix}
\frac{7}{24} & -\frac{1}{24} \\
\frac{13}{24} & \frac{5}{24}
\end{pmatrix}, &
\mathbf{b} &= \begin{pmatrix} \frac{1}{2} \\ \frac{1}{2} \end{pmatrix}.
\end{align*} \end{split}\]
Determining the stability function
\[\begin{split} \begin{align*}
R(z) &= \frac{\det(I - zA + z \mathbf{eb}^T)}{\det(I - zA)} \\
&= \frac{\det \left(
\begin{pmatrix}
1 & 0 \\
0 & 1
\end{pmatrix} - z
\begin{pmatrix}
\frac{7}{24} & -\frac{1}{24} \\
\frac{13}{24} & \frac{5}{24}
\end{pmatrix} + z
\begin{pmatrix}
\frac{1}{2} & \frac{1}{2} \\
\frac{1}{2} & \frac{1}{2}
\end{pmatrix}
\right)}{
\det \left(
\begin{pmatrix}
1 & 0 \\
0 & 1
\end{pmatrix} - z
\begin{pmatrix}
\frac{7}{24} & -\frac{1}{24} \\
\frac{13}{24} & \frac{5}{24}
\end{pmatrix}
\right)
} \\
&= \frac{\det
\begin{pmatrix}
1 + \frac{5}{24}z & \frac{13}{24}z \\
-\frac{1}{24}z & 1 + \frac{7}{24}z
\end{pmatrix}
}{\det
\begin{pmatrix}
1 - \frac{7}{24}z & \frac{1}{24}z \\
-\frac{13}{24}z & 1 - \frac{5}{24}z
\end{pmatrix}
}
= \frac{1 + \frac{1}{2}z + \frac{1}{12}z^2}{1 - \frac{1}{2}z + \frac{1}{12}z^2}.
\end{align*} \end{split}\]
The roots of \(Q(z)\) are \( 3 \pm \sqrt{3}i\) so condition A is satisfied.
\[\begin{split} \begin{align*}
E(y) &= |Q(iy)|^2 - |P(iy)|^2 \\
&= \left| 1 - \frac{1}{2}iy - \frac{1}{12} y^2 \right|^2 - \left| 1 + \frac{1}{2}iy - \frac{1}{12}y^2 \right| \\
&= \left( 1 - \frac{1}{12}y^2 \right)^2 + \frac{1}{4}y^2 - \left( 1 - \frac{1}{12}y^2 \right)^2 - \frac{1}{4}y^2 \\
&= 1 - \frac{1}{6}y^2 + \frac{1}{24}y^4 + \frac{1}{4}y^4 - 1 + \frac{1}{6}y^2 - \frac{1}{24}y^4 - \frac{1}{4}y^2 \\
&= 0.
\end{align*} \end{split}\]
so condition B is also satisfied, so this is an A-stable method.
Exercise 4.3
Plot the region of absolute stability for the fourth-order Gauss-Legendre method. What does your plot suggest about the method?
\[\begin{split} \begin{array}{c|cc}
\frac{1}{2} - \frac{\sqrt{3}}{6} & \frac{1}{4} & \frac{1}{4} - \frac{\sqrt{3}}{6} \\
\frac{1}{2} + \frac{\sqrt{3}}{6} & \frac{1}{4} + \frac{\sqrt{3}}{6} & \frac{1}{4} \\ \hline
& \frac{1}{2} & \frac{1}{2}
\end{array} \end{split}\]
Solution
\[\begin{split} \begin{align*}
A &= \begin{pmatrix}
\frac{1}{4} & \frac{1}{4} - \frac{\sqrt{3}}{6} \\
\frac{1}{4} + \frac{\sqrt{3}}{6} & \frac{1}{4}
\end{pmatrix}, &
\mathbf{b} &= \begin{pmatrix} \frac{1}{2} \\ \frac{1}{2} \end{pmatrix}.
\end{align*} \end{split}\]
Determining the stability function
\[\begin{split} \begin{align*}
R(z) &= \frac{\det (I - zA + z \mathbf{eb}^\mathsf{T})}{\det(I - zA)} \\
&= \frac{
\det\left(
\begin{pmatrix} 1 & 0 \\ 0 & 1 \end{pmatrix} - z
\begin{pmatrix}
\frac{1}{4} & \frac{1}{4} - \frac{\sqrt{3}}{6} \\
\frac{1}{4} + \frac{\sqrt{3}}{6} & \frac{1}{4}
\end{pmatrix} + z
\begin{pmatrix} \frac{1}{2} & \frac{1}{2} \\ \frac{1}{2} & \frac{1}{2} \end{pmatrix}
\right)
}{
\det\left(
\begin{pmatrix} 1 & 0 \\ 0 & 1 \end{pmatrix} - z
\begin{pmatrix}
\frac{1}{4} & \frac{1}{4} - \frac{\sqrt{3}}{6} \\
\frac{1}{4} + \frac{\sqrt{3}}{6} & \frac{1}{4}
\end{pmatrix}
\right)
} \\
&= \frac{\det \begin{pmatrix}
1 + \frac14 z & \left( \frac{1}{4} + \frac{\sqrt{3}}{36} \right)z \\
\left( \frac14 - \frac{\sqrt{3}}{6} \right)z & 1 + \frac14 z
\end{pmatrix}}
{
\det \begin{pmatrix}
1 - \frac14 z & \left(-\frac14 + \frac{\sqrt{3}}{6} \right) z \\
\left( -\frac14 - \frac{\sqrt{3}}{6} \right) z & 1 + \frac14 z
\end{pmatrix}
} \\
&= \frac{1 + \frac{1}{2}z + \frac{1}{12}z^2}{1 - \frac{1}{2}z + \frac{1}{12}z^2}.
\end{align*} \end{split}\]
This is an A-stable method.
Exercise 4.4
Calculate the stiffness ratio for the following system of ODEs.
\[\begin{align*}
y_1' &= -20y_1 + y_2, \\
y_2' &= 500 y_2.
\end{align*}\]
For the Euler method with step size \(h = 0.05\), test the stability against both of the Eigenvalues of this system.
Solution
The eigenvalues are \(\lambda_1 = -20\) and \(\lambda_2 = -500\) so the stiffness ratio is
\[ S = \frac{-500}{-20} = 25. \]
The stability function for the Euler method is \(R(z) = 1 + z = 1 + h \lambda\). For stability, \(|1 + h \lambda| \leq 1\).
For \(\lambda_1\), \(|R(-20 h)| = |1 - 20(0.05)| = 0 < 1\) so is stable.
For \(\lambda_2\), \(|R(-500 h)| = |1 - 500(0.05)| = 24 > 1\) so is unstable.
